Big Tex 14RB + 14RD Roll-Off Dump Trailers + 13BN Dump Bins
Brochure:
Click Here to Download the Big Tex Roll-Off Dump Trailer Brochure
NOTE: These trailers are sold in two parts, the “trailer unit” and the “trailer dump bin”.
These Big Tex roll-off dump trailers are a stocking unit, please contact our sales team for any questions on availability, to make a deposit, or to schedule an appointment. We also sell additional 13BN roll-off dump bins for those customers looking to have multiple bins for their trailer (for those who need to drop-off at multiple locations, or place an empty bin on-site as you transport the filled bin to a landfill).
Big Tex 14RB Roll-Off Dump Trailers
Equipped with the most requested features and 14K GVWR to support the demands of the construction, junk removal, and even the dumpster rental business, the durable 14RB Roll-Off Bumper Pull Dump is built with professional-grade parts and is designed to withstand the rigors of everyday use. From a strong I-beam frame design and scissor-hoist lifting system to an industry-leading heavy-duty winch, the 14RB offers a convenient and cost-effective solution for servicing multiple job sites with a single roll-off dump trailer.
SPECIFICATIONS + DIMENSIONS:
• MODEL: 14RB-14
• BED WIDTH: 83″ wide
• BED LENGTH: 14′ long
• PULL TYPE: Bumper pull
• GVWR: 14,000 lbs
• EMPTY WEIGHT (TRAILER): 3,310 lbs
• EMPTY WEIGHT (BIN): 2,280 lbs
• PAYLOAD CAPACITY: 8,410 lbs
• AXLES: 2 – 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs
• BRAKES: Forward Self-Adjusting Electric Brakes on All Hubs
• SUSPENSION: Multi-Leaf Slipper Spring w/ Equalizer
• COUPLER: 2-5/16″ Ball, Adjustable Demco EZ Latch Coupler
• JACK: 12,000# Drop-Leg Jack (Side Wind)
• FRAME: 8″ Seamless I-Beam (10#)
• CROSS-MEMBERS: 3″ Channel on 16″ Centers
• TOP RAIL: 4″x 3″ Rectangular Tubing
• FLOOR: 10 Gauge Smooth Steel
• FENDERS: 9” x 72” 14 Ga. Diamond Plate Double Square Broke
• TRAILER PLUG: 7-Way RV
• LIGHTS: Recessed, Grommet-Mounted L.E.D. Lighting
• WIRING: Sealed, Modular Cold-Weather Wiring Harness
• TIRES: ST235/80 R-16 Load Range E Radial Tires
• BOLT PATTERN: 8-Lug
• TIE-DOWNS: (4) 1/2″ D-Rings Inside Bed to Secure EquipmentAlong Sides and Rear for Cargo Control
• BREAK-AWAY KIT: Complete Breakaway System w/ Zip Breakaway Cable
• BATTERY: 12V Deep Cycle Gr 24 for Hoist, 12v GR24 AGM for Winch
• CHARGER: (2) 5A 110V on Board Battery Charger for Hydraulic System and Winch
• GATE: Barn Doors
• RAM: Self-Contained Scissor
• SIDES: 48″ Tall (12 Ga) with formed Channel Supports
• STORAGE: Lockable Pump and Battery Box mounted in Front of Bed
• TARP: Fully-Formed Tarp Shroud with Crank Tarp & Rear Tarp Rod Holders
• BATTERY BOX: Tilt Bed mounted Battery Box for Independently wired Winch Power System
• ROLLERS: Greaseable Rollers
• STEPS AND HANDLES: Convenient Side-Step to Access Top Rail
• WINCH: Specially Designed High Duty Cycle 15K Winch
Big Tex 14RD Gooseneck Roll-Off Dump Trailers
The Big Tex 14RD gooseneck roll-off-dump trailer provides superior stability and carrying weight. The 14RD Roll-Off Gooseneck Dump Trailer features a 15,900 lbs. GVWR to meet the demands of the construction, junk removal, and the dumpster rental business. Built to service multiple job sites with a single trailer, it’s designed with professional-grade parts to hold up against the challenges of day-to-day use. From a strong I-beam frame design and scissor-hoist lifting system to an industry-leading heavy-duty winch, the gooseneck configured 14RD gets the job done when the going gets tough.
SPECIFICATIONS + DIMENSIONS:
• MODEL: 14RD-14
• BED WIDTH: 83″ wide
• BED LENGTH: 14′ long
• PULL TYPE: Bumper pull
• GVWR: 15,900 lbs
• EMPTY WEIGHT (TRAILER): 3,760 lbs
• EMPTY WEIGHT (BIN): 2,280 lbs
• PAYLOAD CAPACITY: 9,860 lbs
• AXLES: 2 – 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs
• BRAKES: Forward Self-Adjusting Electric Brakes on All Hubs
• SUSPENSION: Multi-Leaf Slipper Spring w/ Equalizer
• COUPLER: 2-5/16″ Ball, Adjustable Demco EZ Latch Coupler
• JACK: 12,000# Drop-Leg Jack (Side Wind)
• FRAME: 8″ Seamless I-Beam (10#)
• CROSS-MEMBERS: 3″ Channel on 16″ Centers
• TOP RAIL: 4″x 3″ Rectangular Tubing
• FLOOR: 10 Gauge Smooth Steel
• FENDERS: 9” x 72” 14 Ga. Diamond Plate Double Square Broke
• TRAILER PLUG: 7-Way RV
• LIGHTS: Recessed, Grommet-Mounted L.E.D. Lighting
• WIRING: Sealed, Modular Cold-Weather Wiring Harness
• TIRES: ST235/80 R-16 Load Range E Radial Tires
• BOLT PATTERN: 8-Lug
• TIE-DOWNS: (4) 1/2″ D-Rings Inside Bed to Secure EquipmentAlong Sides and Rear for Cargo Control
• BREAK-AWAY KIT: Complete Breakaway System w/ Zip Breakaway Cable
• BATTERY: 12V Deep Cycle Gr 24 for Hoist, 12v GR24 AGM for Winch
• CHARGER: (2) 5A 110V on Board Battery Charger for Hydraulic System and Winch
• GATE: Barn Doors
• RAM: Self-Contained Scissor
• SIDES: 48″ Tall (12 Ga) with formed Channel Supports
• STORAGE: Lockable Pump and Battery Box mounted in Front of Bed
• TARP: Fully-Formed Tarp Shroud with Crank Tarp & Rear Tarp Rod Holders
• BATTERY BOX: Tilt Bed mounted Battery Box for Independently wired Winch Power System
• ROLLERS: Greaseable Rollers
• STEPS AND HANDLES: Convenient Side-Step to Access Top Rail
• WINCH: Specially Designed High Duty Cycle 15K Winch
