Big Tex 14EH Heavy Duty Tandem Axle Seamless I-Beam Equipment Trailer
Part of the all-new X-Series, the 14EH Equipment Trailer from Big Tex Trailers is engineered for professionals who demand durability and innovation. The 14EH features a Mega-Sized Toolbox for added storage capacity. It’s enhanced with a Full-Length Rub Rail, D-Rings, and Stake Pockets, providing multiple secure tie-down options for a variety of cargo. The 14EH revolutionizes loading and unloading with its optional Self-Stabilizing Mega Ramps, offering unparalleled flexibility for all your hauling needs.
This is a stocking unit, please contact our sales team for any questions on availability, to make a deposit, or to schedule an appointment.
SPECIFICATIONS + DIMENSIONS:
• MODEL: 14EH-20D3A
• BED WIDTH: 83″ wide (between fenders)
• BED LENGTH: 20′ long (40″ cleated dovetail)
• GVWR: 15,400 lbs
• EMPTY WEIGHT: 3,150 lbs
• PAYLOAD CAPACITY: 12,250 lbs
• AXLES: 2 – 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs
• BRAKES: Forward Self-Adjusting Electric Brakes on All Hubs
• SUSPENSION: Multi-Leaf Slipper Spring w/ Equalizer
• COUPLER: Adjustable 2-5/16” Demco EZ Latch
• JACK: 12,000# Drop-Leg Jack (Side Wind)
• FRAME: 8″ I-Beam
• CROSS-MEMBERS: 3″ Channel on 16″ Centers
• FRONT STOP RAIL: 3/16″ Fabricated Front Stop Rail
• FLOOR: Treated Pine Floor
• FENDERS: 9” x 72” 14 Ga. Diamond Plate Double Square Broke w/Back (Removable)
• RAMPS: 36″ Wide Mega Ramps
• DOVETAIL: 40” Cleated Dovetail
• TRAILER PLUG: 7-Way RV
• LIGHTS: L.E.D. D.O.T. Stop, Tail, Turn & Clearance
• WIRING: Sealed, Modular Cold-Weather Wiring Harness
• TIRES: ST235/80 R-16 Load Range E Radial Tires
• BOLT PATTERN: 8-Lug
• RUBRAIL: Rub Rail Along Both Sides
• STAKE POCKETS: Stake Pockets Along Both Sides (Quantity Varies by Length)
• TIE-DOWNS: (6) 5/8″ D-Rings
• BREAK-AWAY KIT: Complete Breakaway System w/ Zip Breakaway Cable
• STORAGE: Lockable Toolbox Between Risers on Gooseneck Model, Mega-Sized Integrated Tongue Box with Lockable Lid (Bumper Pull Only)
• STEP & HANDLES: Convenient Side-Step to Access Deck
